Tp-Link 24 Port Gigabit Switch TL-SG1048

Key Features

Innovative energy-efficient technology saves power consumption
100% Data filtering rate eliminates all error packets
Supports IEEE 802.3x flow control for Full Duplex mode and back pressure for Half Duplex mode
Non-blocking switching architecture forwards and filters packets at full wire-speed for maximum throughput
96Gbps Switching Capacity
Auto MDI/MDIX eliminates the need for crossover cables
Supports MAC address auto-learning and auto-aging
Support the port N-Way Auto-Negotiation, Store and Forward.
Compact size design for desktops, Rack mountable
Plug and Play design simplifies installation

Tp-Link 24 Port Gigabit Switch TL-SG1048

Name: Tp-Link 24 Port Gigabit Switch TL-SG1048
SKU: 5277
Availability: InStock

What This Product Does
The 48-Port Gigabit Switch TL-SG1048 is designed to meet the needs of the most demanding work group and departmental connectivity requirements. A reliable, easy-to-use switch without the complexity of management, the TL-SG1048 provides 48 10/100/1000Mbps ports. The TL-SG1048 combines ease of use with unsurpassed performance resulting in an exceptional value for any cost-conscious network administrator who wants the best possible solution at the best possible price.

TP-Link Green Technology
This new generation 48-Port Gigabit Rack mount Switch TL-SG1048 features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status to limit the carbon footprint of your network. It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, 80% of the packaging material can be recycled.

Ease of Use
The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDI-X crossover on all ports eliminate the need for crossover cables or uplink ports. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance. Compact size shell make it ideal for desktops with limited space while it is also Rack mountable, convenient and safe. Dynamic LED lights provide real-time work status display and basic fault diagnosis.

High Performance
The TL-SG1048 features non-blocking wire-speed architecture with a 96Gbps switching capacity for maximum data throughput. An 8K MAC address table provides scalability for even the largest networks. It also supports 802.3x Flow Control for full-duplex mode, and back pressure flow control for half-duplex mode alleviates traffic congestion and ensures reliable data transmission. Read more about Tp-Link Switches.

Specifications
Hardware Features

Standards and Protocols : IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Interface :    48 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media :    10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
Power Supply : 100-240VAC, 50/60Hz
Power Consumption :    Maximum: 32.3W (220V/50Hz)
Dimensions ( W x D x H ) : 17.32*8.7*1.73 in.(440*220*44 mm)

Performance

Switching Capacity : 96Gbps
Packet Forwarding Rate : 71.4Mpps
MAC Address Table : 8K
Buffer Memory : 12Mb
Jumbo Frame : 12KB
Transfer Method : Store-and-Forward
